| DN4 | AD9,53 | 95 mm-10,5 mm | 1/8" | 0,003-0,142 m³/h
0,047-2,374 l/min
0,013-0,627 gal/min |
| DN8 | AD12,7 | 12,4 mm-13,1 mm | 1/4" | 0,011-0,570 m³/h
0,190-9,496 l/min
0,050-2,509 gal/min |
| DN10 | AD15 | 14,5 mm-15,4 mm | 3/8" | 0,026-1,282 m³/h
0,427-21,366 l/min
0,113-5,644 gal/min |
| DN15 | AD20 | 16,5 mm-23,0 mm | 1/2" | 0,046-2,279 m³/h
0,760-37,984 l/min
0,201-10,034 gal/min |
| DN20 | AD25 | 25,0 mm-30,0 mm | 3/4" | 0,103-5,128 m³/h
1,709-85,464 l/min
0,452-22,577 gal/min |
| DN25 | AD32 | 32,0 mm-35,0 mm | 1" | 0,182-9,116 m³/h
3,039-151,935 l/min
0,803-40,137 gal/min |
| DN32 | AD40 | 38,0 mm-45,0 mm | 1-1/4" | 0,285-14,244 m³/h
4,748-237,399 l/min
1,254-62,714 gal/min |
| DN40 | AD50 | 48,0 mm-54,0 mm | 1-1/2" | 0,410-20,511 m³/h
6,837-341,854 l/min
1,806-90,309 gal/min |
| DN50 | AD63 | 58,0 mm-64,0 mm | 2" | 0,729-36,464 m³/h
12,155-607,741 l/min
3,211-160,549 gal/min |
| DN65 | AD75 | 72,0 mm-78,0 mm | 2-1/2" | 1,140-56,976 m³/h
18,992-949,595 l/min
5,017-250,857 gal/min |
| DN80 | AD90 | 80,0 mm-92,0 mm | 3" | 1,641-82,045 m³/h
27,348-1367,417 l/min
7,225-361,234 gal/min |
| DN100 | AD110 | 108,0 mm-116,0 mm | 4" | 2,917-145,858 m³/h
48,619-2430,963 l/min
12,844-642,194 gal/min |
| DN125 | AD140 | 132,0 mm-142,0 mm | 5" | 4,558-227,903 m³/h
75,968-3798,380 l/min
20,069-1003,429 gal/min |
| DN200 | AD220 | 218,0 mm-228,0 mm | 8" | 11,669-583,431 m³/h
194,477-9723,852 l/min
51,376-2568,778 gal/min |
