| DN |
AD |
AD-Bereich |
Zoll |
Durchflussbereich |
| DN4 |
AD9,53 |
95mm-10,5mm |
1/8" |
0,003-0,142 m³/h
0,047-2,374 l/min
0,013-0,627 gal/min |
| DN8 |
AD12,7 |
12,4mm-13,1mm |
1/4" |
0,011-0,570 m³/h
0,190-9,496 l/min
0,050-2,509 gal/min |
| DN10 |
AD15 |
14,5mm-15,4mm |
3/8" |
0,026-1,282 m³/h
0,427-21,366 l/min
0,113-5,644 gal/min |
| DN15 |
AD20 |
16,5mm-23,0mm |
1/2" |
0,046-2,279 m³/h
0,760-37,984 l/min
0,201-10,034 gal/min |
| DN20 |
AD25 |
25,0mm-30,0mm |
3/4" |
0,103-5,128 m³/h
1,709-85,464 l/min
0,452-22,577 gal/min |
| DN25 |
AD32 |
32,0mm-35,0mm |
1" |
0,182-9,116 m³/h
3,039-151,935 l/min
0,803-40,137 gal/min |
| DN32 |
AD40 |
38,0mm-45,0mm |
1-1/4" |
0,285-14,244 m³/h
4,748-237,399 l/min
1,254-62,714 gal/min |
| DN40 |
AD50 |
48,0mm-54,0mm |
1-1/2" |
0,410-20,511 m³/h
6,837-341,854 l/min
1,806-90,309 gal/min |
| DN50 |
AD63 |
58,0mm-64,0mm |
2" |
0,729-36,464 m³/h
12,155-607,741 l/min
3,211-160,549 gal/min |
| DN65 |
AD75 |
72,0mm-78,0mm |
2-1/2" |
1,140-56,976 m³/h
18,992-949,595 l/min
5,017-250,857 gal/min |
| DN80 |
AD90 |
80,0mm-92,0mm |
3" |
1,641-82,045 m³/h
27,348-1367,417 l/min
7,225-361,234 gal/min |
| DN100 |
AD110 |
108,0mm-116,0mm |
4" |
2,917-145,858 m³/h
48,619-2430,963 l/min
12,844-642,194 gal/min |
| DN125 |
AD140 |
132,0mm-142,0mm |
5" |
4,558-227,903 m³/h
75,968-3798,380 l/min
20,069-1003,429 gal/min |
| DN200 |
AD220 |
218,0mm-228,0mm |
8" |
11,669-583,431 m³/h
194,477-9723,852 l/min
51,376-2568,778 gal/min |
